0190570026
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Terminal Ring Connector
PDF
/
Inventory: 1731
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Material - Insulation Polyamide (PA66), Nylon 6/6
Technical
Packaging Bulk
Series Avikrimp
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Color Red
Contact Finish Electro-Tin
Wire Gauge 18-22 AWG
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 18 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Diameter 0.140 (3.56mm)
Insulation Insulated
Terminal Type Circular
Stud/Tab Size 4 Stud
Dimensions
Length 24.2062mm
Thickness 0.028 0.71mm
Length - Overall 0.953 24.21mm
Width - Outer Edges 0.264 6.70mm
Compliance
RoHS Status ROHS3 Compliant
