0190540108
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 14-16AWG #6 CRIMP
PDF
/
Buying Options
Total Price: USD $0.21
Unit Price: USD $0.2112
≥1 USD $0.2112
≥10 USD $0.16544
≥100 USD $0.118976
≥500 USD $0.093078
≥1000 USD $0.085325
Inventory: 526
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mounting Type Free Hanging (In-Line)
Material - Insulation Poly-Vinyl Chloride (PVC)
Technical
Packaging Bulk
Series InsulKrimp
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Color Blue
Contact Finish Electro-Tin
Wire Gauge 14-16 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Diameter 0.175 (4.45mm)
Insulation Insulated
Terminal Type Circular
Stud/Tab Size 6 Stud
Dimensions
Thickness 0.031 0.79mm
Length - Overall 0.926 23.52mm
Width - Outer Edges 0.312 7.92mm
Compliance
RoHS Status ROHS3 Compliant
