0190540099
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Terminal Ring Connector
PDF
/
Buying Options
Total Price: USD $0.68
Unit Price: USD $0.6776
≥1 USD $0.6776
≥10 USD $0.56408
≥100 USD $0.470008
Inventory: 12324
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Material - Insulation Poly-Vinyl Chloride (PVC)
Body Material Copper
Technical
Packaging Tape & Reel (TR)
Series InsulKrimp
Feature Heavy Duty
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Color Blue
Depth 13.7mm
Contact Finish Electro-Tin
Wire Gauge 14-16 AWG
Wire Gauge (Max) 16 AWG
Wire Gauge (Min) 14 AWG
Body Plating Tin
Insulation Diameter 0.250 (6.35mm)
Insulation Insulated
Terminal Type Circular
Stud/Tab Size 5/16 Stud
Dimensions
Length 31.5722mm
Thickness 0.050 1.27mm
Length - Overall 1.243 31.57mm
Width - Outer Edges 0.540 13.72mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Alternative Model
