RV18-8Q

3M
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description 3M RV18-8QTERMINAL, RING TONGUE, STUD 8, CRIMP, RED
PDF
/
Buying Options
Total Price: USD $0.67
Unit Price: USD $0.6688
≥1 USD $0.6688
≥10 USD $0.58256
≥100 USD $0.5324
≥500 USD $0.501248
≥1000 USD $0.480304
≥3000 USD $0.438557
Inventory: 432
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant
REACH SVHC Unknown

Dimensions

Width - Outer Edges 0.310 7.87mm
Length - Overall 0.930 23.62mm
Thickness 0.030 0.76mm
Width 139.7mm
Length 23.622mm
Height 114.3mm

Technical

Stud Size M4
Stud/Tab Size 8 Stud
Terminal Type Circular
Insulation Insulated
Insulation Diameter 0.145 (3.68mm)
Wire/Cable Gauge 18 AWG
Wire Gauge (Min) 18 AWG
Wire Gauge (Max) 22 AWG
Wire Gauge 18-22 AWG
Approval Agency CSA, UL
Contact Finish Tin
Orientation Straight
Color Red
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Butted Seam
Series Highland?
Published 2000
Packaging Bulk

Physical

Material - Insulation Vinyl
Weight 317.514659g
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper, ETP

Supply Chain

Factory Lead Time 3 Weeks
