RV18-14C
RoHS
/
Package 100
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 18-22AWG #1/4
PDF
/
Inventory: 7683
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Contact Material Copper, ETP
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Package / Case 100
Weight 681.29574g
Material - Insulation Vinyl
Technical
Packaging Bulk
Published 2008
Series Highland?
Feature Butted Seam
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Color Red
Contact Finish Tin
Wire Gauge 18-22 AWG
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 18 AWG
Insulation Diameter 0.145 (3.68mm)
Insulation Insulated
Terminal Type Circular
Stud/Tab Size 1/4 Stud
Dimensions
Length 27.432mm
Thickness 0.030 0.76mm
Length - Overall 1.080 27.43mm
Width - Outer Edges 0.470 11.94mm
Compliance
RoHS Status RoHS Compliant
