RV10-14Q
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Terminals RING VNYL INS HIGHLAND BAG, 25/BAG
PDF
/
Inventory: 5643
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Copper, ETP
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Weight 771.107029g
Material - Insulation Vinyl
Body Material Copper
Technical
Packaging Bulk
Published 2008
Series Highland?
Feature Butted Seam
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Color Yellow
Gender Female
Voltage - Rated 1kV
Voltage - Rated DC 1kV
Orientation Straight
Depth 13.46mm
Approval Agency CSA, UL
Wire Gauge 10-12 AWG
Wire Gauge (Max) 12 AWG
Wire Gauge (Min) 10 AWG
Wire/Cable Gauge 10 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Diameter 0.250 (6.35mm)
Insulation Insulated
Terminal Type Circular
Stud/Tab Size 1/4 Stud
Dimensions
Height 114.3mm
Length 32mm
Width 139.7mm
Thickness 0.040 1.02mm
Length - Overall 1.260 32.00mm
Width - Outer Edges 0.530 13.46mm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
