MV18-4R/SX-BOTTLE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Terminal Ring Connector
PDF
/
Buying Options
Total Price: USD $229.44
Unit Price: USD $229.439778
≥1 USD $229.439778
≥200 USD $91.548517
≥500 USD $88.48946
≥1000 USD $86.978312
Inventory: 2546
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width - Outer Edges 0.250 6.35mm
Length - Overall 0.800 20.32mm
Thickness 0.030 0.76mm
Technical
Stud/Tab Size 4 Stud
Terminal Type Circular
Insulation Insulated
Insulation Diameter 0.145 (3.68mm)
Wire Gauge 18-22 AWG
Contact Finish Tin
Color Red
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Brazed Seam
Series Scotchlok?
Published 2000
Packaging Bulk
Physical
Material - Insulation Vinyl
Mounting Type Free Hanging (In-Line)
Contact Material Copper, ETP
Supply Chain
Factory Lead Time 3 Weeks
