MV14-38RX-BOTTLE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Terminal Ring Connector
PDF
/
Buying Options
Total Price: USD $246.87
Unit Price: USD $246.873777
≥1 USD $246.873777
≥200 USD $98.504261
≥500 USD $95.212821
≥1000 USD $93.586138
Inventory: 2222
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width - Outer Edges 0.560 14.22mm
Length - Overall 1.130 28.70mm
Thickness 0.030 0.76mm
Technical
Stud/Tab Size 3/8 Stud
Terminal Type Circular
Insulation Insulated
Insulation Diameter 0.170 (4.32mm)
Wire Gauge 14-16 AWG
Contact Finish Tin
Color Blue
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Brazed Seam
Series Scotchlok?
Published 2009
Packaging Bulk
Physical
Material - Insulation Vinyl
Mounting Type Free Hanging (In-Line)
Contact Material Copper, ETP
Supply Chain
Factory Lead Time 3 Weeks
