MNG14-14R/SK
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Terminals C-01-512K 12-14S-NB 79847
PDF
/
Buying Options
Total Price: USD $1.07
Unit Price: USD $1.068986
≥1 USD $1.068986
≥10 USD $1.008476
≥100 USD $0.951395
≥500 USD $0.897541
≥1000 USD $0.846736
Inventory: 5197
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width - Outer Edges 0.470 11.94mm
Length - Overall 1.090 27.69mm
Thickness 0.030 0.76mm
Length 27.68mm
Technical
Stud/Tab Size 1/4 Stud
Terminal Type Circular
Insulation Insulated
Insulation Diameter 0.170 (4.32mm)
Wire Gauge (Min) 14 AWG
Wire Gauge (Max) 16 AWG
Wire Gauge 14-16 AWG
Contact Finish Tin
Depth 11.93mm
Color Blue
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Scotchlok?
Published 2000
Packaging Bulk
Physical
Body Material Copper
Material - Insulation Polyamide (PA), Nylon
Weight 1.556275kg
Mounting Type Free Hanging (In-Line)
Contact Material Copper, ETP
Supply Chain
Factory Lead Time 3 Weeks
