MN24-4RK
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
CONN RING CIRC 24-26AWG #4 CRIMP
PDF
/
Buying Options
Total Price: USD $1.92
Unit Price: USD $1.920665
≥1 USD $1.920665
≥10 USD $1.811942
≥100 USD $1.709389
≥500 USD $1.612625
≥1000 USD $1.521349
Inventory: 5854
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Width - Outer Edges 0.200 5.08mm
Thickness 0.020 0.51mm
Length 15.24mm
Technical
Stud/Tab Size 4 Stud
Terminal Type Circular
Insulation Insulated
Insulation Diameter 0.090 (2.29mm)
Wire/Cable Gauge 22 AWG
Wire Gauge (Min) 24 AWG
Wire Gauge (Max) 26 AWG
Wire Gauge 24-26 AWG
Contact Finish Tin
Depth 5.08mm
Orientation Straight
Color Yellow
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Brazed Seam
Series Scotchlok?
Published 2000
Packaging Bulk
Physical
Material - Insulation Polyamide (PA), Nylon
Weight 354.88999g
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
Supply Chain
Factory Lead Time 3 Weeks
