M18-6R/SK

3M
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description Ring Tongue Terminal 18-22AWG 15.24mm 6.35mm Tin Case
PDF
/
Buying Options
Total Price: USD $0.62
Unit Price: USD $0.622315
≥1 USD $0.622315
≥200 USD $0.249451
≥500 USD $0.240261
≥1000 USD $0.236322
Inventory: 6593
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Width - Outer Edges 0.250 6.35mm
Length - Overall 0.600 15.24mm
Thickness 0.030 0.76mm
Length 15.24mm

Technical

Stud/Tab Size 6 Stud
Terminal Type Circular
Insulation Non-Insulated
Body Plating Tin
Wire Gauge (Min) 18 AWG
Wire Gauge (Max) 22 AWG
Wire Gauge 18-22 AWG
Depth 6.35mm
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Brazed Seam
Series Scotchlok?
Published 2009
Packaging Bulk

Physical

Body Material Copper
Weight 639.565242g
Mounting Type Free Hanging (In-Line)

Supply Chain

Factory Lead Time 3 Weeks
