L-12-6-NB
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description
Ring Tongue Terminal 14-16AWG 23.87mm 7.87mm Tin
PDF
/
Inventory: 2423
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Weight 1.17934g
Material - Insulation Polyamide (PA), Nylon
Body Material Copper
Technical
Packaging Bulk
Published 2015
Feature Butted Seam
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Color Blue
Depth 7.87mm
Wire Gauge 14-16 AWG
Wire Gauge (Max) 16 AWG
Wire Gauge (Min) 14 AWG
Body Plating Tin
Insulation Diameter 0.170 (4.32mm)
Insulation Insulated
Terminal Type Circular
Stud/Tab Size 6 Stud
Dimensions
Length 23.876mm
Thickness 0.030 0.76mm
Length - Overall 0.940 23.88mm
Width - Outer Edges 0.310 7.87mm
Compliance
RoHS Status Non-RoHS Compliant
