L-11-6-NB

3M
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description Ring Tongue Terminal 18-22AWG 23.36mm 7.87mm Tin
PDF
/
Inventory: 4734
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant

Dimensions

Width - Outer Edges 0.310 7.87mm
Length - Overall 0.770 19.56mm
Thickness 0.030 0.76mm
Length 19.558mm

Technical

Stud/Tab Size 6 Stud
Terminal Type Circular
Insulation Insulated
Insulation Diameter 0.145 (3.68mm)
Body Plating Tin
Wire Gauge (Min) 18 AWG
Wire Gauge (Max) 22 AWG
Wire Gauge 18-22 AWG
Depth 7.87mm
Color Red
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Butted Seam
Published 2002
Packaging Bulk

Physical

Body Material Copper
Material - Insulation Polyamide (PA), Nylon
Weight 1.043262g
Mounting Type Free Hanging (In-Line)
Mount Free Hanging

Supply Chain

Factory Lead Time 3 Weeks
