11-8S-NB

3M
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Ring Connectors
Description CONN RING CIRC 18-22AWG #8 CRIMP
PDF
/
Buying Options
Total Price: USD $0.41
Unit Price: USD $0.4136
≥1 USD $0.4136
≥10 USD $0.35112
≥100 USD $0.309408
≥500 USD $0.28424
≥1000 USD $0.273064
≥3000 USD $0.245203
Inventory: 927
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width - Outer Edges 0.250 6.35mm
Length - Overall 0.790 20.07mm
Thickness 0.030 0.76mm
Length 20.066mm

Technical

Stud/Tab Size 8 Stud
Terminal Type Circular
Insulation Insulated
Insulation Diameter 0.145 (3.68mm)
Wire Gauge (Min) 18 AWG
Wire Gauge (Max) 22 AWG
Wire Gauge 18-22 AWG
Color Red
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Butted Seam
Published 2015
Packaging Bulk

Physical

Material - Insulation Polyamide (PA), Nylon
Weight 860.011134mg
Mounting Type Free Hanging (In-Line)
Mount Free Hanging

Supply Chain

Factory Lead Time 3 Weeks
