RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description Terminal Rectangular Connector
PDF
/
Buying Options
Total Price: USD $117.15
Unit Price: USD $117.15138
≥1 USD $117.15138
≥200 USD $46.744492
≥500 USD $45.182141
≥1000 USD $44.411468
Inventory: 9615
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Diameter - Ring ID 0.390 (9.91mm)
Diameter - Barrel OD 0.820 (20.83mm)
Diameter - Barrel ID 0.648 (16.46mm)
Tab Thickness 0.280 7.11mm
Width - Outer Edges 0.830 21.08mm
Length - Overall 3.510 89.15mm

Technical

Terminal Style Single Stud Hole
Stud/Tab Size 3/8 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Wire Gauge 4/0 AWG
Contact Finish Tin
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Ampower
Published 2008
Packaging Bulk

Physical

Mounting Type Free Hanging (In-Line)
Contact Material Copper

Supply Chain

Factory Lead Time 17 Weeks
