605685-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Power Terminal (4/0)AWG 102.9mm 30.2mm Tin Box
PDF
/
Buying Options
Total Price: USD $78.21
Unit Price: USD $78.20814
≥1 USD $78.20814
≥200 USD $31.20632
≥500 USD $30.162565
≥1000 USD $29.647908
Inventory: 3074
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Diameter - Ring ID 0.390 (9.91mm)
Diameter - Barrel OD 0.980 (24.89mm)
Diameter - Barrel ID 0.648 (16.46mm)
Tongue Thickness 3.302mm
Tab Thickness 0.130 3.30mm
Width - Outer Edges 1.190 30.23mm
Length - Overall 4.050 102.90mm
Length 102.87mm
Technical
Number of Holes 2
Government Qualified No
Stud Diameter 9.906 mm
Heavy Duty Yes
Terminal Style Two Stud Holes
Stud/Tab Size 3/8 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Sealable No
Body Plating Tin
Plating Tin
ELV Compliant
Wire Gauge 4/0 AWG
Contact Finish Tin
Depth 30.2mm
Gender Male
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Ampower
Published 2002
Packaging Bulk
Physical
Body Material Copper
Material Copper
Mounting Type Free Hanging (In-Line)
Mount Standard
Contact Material Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 17 Weeks
