55782-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Terminals TERM SOLIS TRAND 12-10 8
PDF
/
Buying Options
Total Price: USD $0.64
Unit Price: USD $0.6424
≥1 USD $0.6424
≥10 USD $0.62304
≥100 USD $0.445315
≥500 USD $0.390298
≥1000 USD $0.340534
≥3000 USD $0.324192
Inventory: 4883
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
Dimensions
Diameter - Ring ID 0.171 (4.34mm)
Diameter - Barrel OD 0.226 (5.74mm)
Diameter - Barrel ID 0.129 (3.28mm)
Tongue Thickness 990μm
Tab Thickness 0.039 0.99mm
Width - Outer Edges 0.400 10.16mm
Diameter - Inside 3.28 mm
Length - Overall 0.992 25.20mm
Length 25.2mm
Technical
Stud Size M4
Number of Holes 1
Stud Diameter 4.1656 mm
Insulated Wire Support Yes
Terminal Style Single Stud Hole
Stud/Tab Size 8 Stud
Wire Cross Section 6.64 mm2
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Insulation Diameter 5.7404 mm
Terminal and Terminal Block Type RING TERMINAL
Sealable No
Wire Gauge (Min) 12 AWG
Wire Gauge (Max) 10 AWG
ELV Compliant
Wire Gauge 10-12 AWG
Depth 10.16mm
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Brazed Seam, Serrated Termination
Series Solistrand
Published 1999
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Contact Plating Tin
Contact Material Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 11 Weeks
