42673-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Terminals RING10-8 10 .040TPBR
PDF
/
Buying Options
Total Price: USD $0.33
Unit Price: USD $0.3344
≥1 USD $0.3344
≥10 USD $0.30536
≥100 USD $0.304128
≥500 USD $0.297968
≥1000 USD $0.254584
≥3000 USD $0.229152
Inventory: 9066
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
Dimensions
Diameter - Ring ID 0.197 (5.00mm)
Tongue Thickness 1.016mm
Material Thickness 1.016mm
Tab Thickness 0.040 1.02mm
Width - Outer Edges 0.385 9.78mm
Diameter - Inside 3.3 mm
Length - Overall 0.717 18.21mm
Length 18.2118mm
Technical
Number of Holes 1
Stud Diameter 4.82 mm
Heavy Duty No
Terminal Style Single Stud Hole
Stud/Tab Size 10 Stud
Terminal Type Ring
Insulation Non-Insulated
Wire Gauge (Min) 8 AWG
Wire Gauge (Max) 10 AWG
ELV Compliant
Wire Gauge 8-10 AWG
Contact Finish Tin
Orientation Straight
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 1997
Packaging Tape & Reel (TR)
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 4 Weeks
