RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
CONN TERM RECT TONG 14-16 AWG #8
PDF
/
Buying Options
Total Price: USD $0.7
Unit Price: USD $0.704
≥1 USD $0.704
≥10 USD $0.6732
≥100 USD $0.5544
≥500 USD $0.435811
≥1000 USD $0.373551
≥3000 USD $0.366916
Inventory: 4619
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
Dimensions
Diameter - Ring ID 0.171 (4.34mm)
Tongue Thickness 790μm
Material Thickness 790μm
Tab Thickness 0.031 0.79mm
Width - Outer Edges 0.244 6.20mm
Diameter - Inside 4.39 mm
Length - Overall 0.856 21.74mm
Plating Thickness 2.54μm
Length 21.74mm
Technical
Stud Size M4
Number of Holes 1
Stud Diameter 4.34 mm
Heavy Duty No
Insulated Wire Support Yes
Terminal Style Single Stud Hole
Stud/Tab Size 8 Stud
Wire Cross Section 2 mm2
Wire/Cable Diameter 4.318 mm
Terminal Type Rectangular Tongue
Insulation Insulated
Insulation Diameter 4.318 mm
Terminal and Terminal Block Type RING TERMINAL
Wire Gauge (Min) 14 AWG
Wire Gauge (Max) 16 AWG
ELV Compliant
Wire Gauge 14-16 AWG
Voltage - Rated AC 300V
Depth 6.2mm
HTS Code 8536.90.40.00
Color Blue
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Serrated Termination
Series PIDG
Published 2008
Packaging Bulk
Physical
Insulation Material Nylon
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 14 Weeks
