327292-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Heavy Duty Power Connectors TERM AMPOWER 800MCM 1/2 UNPLTD
PDF
/
Buying Options
Total Price: USD $161.2
Unit Price: USD $161.203114
≥1 USD $161.203114
≥200 USD $64.321597
≥500 USD $62.17238
≥1000 USD $61.110243
Inventory: 9462
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Diameter - Ring ID 0.562 (14.27mm)
Diameter - Barrel OD 1.543 (39.19mm)
Diameter - Barrel ID 1.242 (31.55mm)
Tongue Thickness 6.35mm
Tab Thickness 0.250 6.35mm
Width - Outer Edges 2.260 57.40mm
Diameter - Inside 31.55 mm
Length - Overall 5.230 132.84mm
Length 132.83946mm
Technical
Stud Size M12
Number of Holes 2
Government Qualified No
Stud Diameter 14.2748 mm
Heavy Duty No
Insulated Wire Support No
Terminal Style Two Stud Holes
Stud/Tab Size 1/2 Stud
Terminal Type Standard
Insulation Non-Insulated
Sealable No
Plating Unplated
ELV Compliant
Wire Gauge 800MCM (kcmil)
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Ampower
Published 2008
Packaging Bulk
Physical
Material Copper
Mounting Type Free Hanging (In-Line)
Contact Material Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 16 Weeks
