RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
CONN TERM RECT 4/0 AWG #3/8
PDF
/
Buying Options
Total Price: USD $13.1
Unit Price: USD $13.1032
≥1 USD $13.1032
≥10 USD $12.83304
≥100 USD $12.491424
≥500 USD $11.877184
≥1000 USD $10.716816
≥3000 USD $10.648528
Inventory: 581
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Diameter - Ring ID 0.390 (9.91mm)
Diameter - Barrel OD 0.807 (20.50mm)
Diameter - Barrel ID 0.648 (16.46mm)
Tongue Thickness 3.302mm
Tab Thickness 0.130 3.30mm
Width - Outer Edges 1.190 30.23mm
Diameter - Inside 16.46 mm
Length - Overall 3.460 87.88mm
Length 87.87892mm
Technical
Number of Holes 2
Stud Diameter 9.906 mm
Heavy Duty No
Terminal Style Two Stud Holes
Stud/Tab Size 3/8 Stud
Terminal Type Standard
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
ELV Compliant
Wire Gauge 4/0 AWG
Depth 20.32mm
Orientation Straight
HTS Code 8536.90.40.00
Gender Female
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Ampower
Published 2003
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 13 Weeks
