326005 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description CONN TERM RECT TONG 400 MCM #1/2
PDF
/
Buying Options
Total Price: USD $28.72
Unit Price: USD $28.7232
≥1 USD $28.7232
≥10 USD $22.037664
≥100 USD $20.365928
Inventory: 626
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Diameter - Ring ID 0.515 (13.08mm)
Diameter - Barrel OD 1.095 (27.81mm)
Diameter - Barrel ID 0.876 (22.25mm)
Tongue Thickness 4.57mm
Tab Thickness 0.180 4.57mm
Width - Outer Edges 1.610 40.89mm
Diameter - Inside 22.25 mm
Length - Overall 2.890 73.41mm
Length 73.41mm

Technical

Stud Size M12
Number of Holes 1
Stud Diameter 13.08 mm
Heavy Duty No
Terminal Style Single Stud Hole
Stud/Tab Size 1/2 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Max Voltage Rating (AC) 250V
ELV Compliant
Wire Gauge 400MCM (kcmil)
UL Flammability Code 94V-0
Contact Gender FEMALE
Voltage - Rated AC 250V
Current Rating 5A
Depth 40.89mm
Total Number of Contacts 64
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.69.40.40
Additional Feature POLARIZED
Number of Rows 2
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Resistance 51.8mOhm
Connector Type CARD EDGE CONNECTOR
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e3
Series Ampower
Published 2012
Packaging Bulk

Physical

Number of Pins 2
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 17 Weeks
