RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Heavy Duty Power Connectors TERMINAL AMPOWER 250MCM 5/16
PDF
/
Buying Options
Total Price: USD $41.16
Unit Price: USD $41.164667
≥1 USD $41.164667
≥200 USD $16.425692
≥500 USD $15.8769
≥1000 USD $15.605129
Inventory: 5443
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Diameter - Ring ID 0.328 (8.33mm)
Diameter - Barrel OD 0.871 (22.12mm)
Diameter - Barrel ID 0.690 (17.53mm)
Tongue Thickness 3.81mm
Tab Thickness 0.150 3.81mm
Width - Outer Edges 1.280 32.51mm
Diameter - Inside 17.53 mm
Length - Overall 2.580 65.53mm
Length 65.532mm
Technical
Stud Size M8
Number of Holes 1
Stud Diameter 8.3312 mm
Heavy Duty No
Terminal Style Single Stud Hole
Stud/Tab Size 5/16 Stud
Terminal Type Standard
Insulation Non-Insulated
ELV Compliant
Wire Gauge 250MCM (kcmil)
Contact Finish Tin
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Connector Type BOARD CONNECTOR
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Ampower
Published 2016
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Contact Material Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 14 Weeks
