RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
CONN TERM RECT TONG 3/0 AWG #1/2
PDF
/
Buying Options
Total Price: USD $16.3
Unit Price: USD $16.2976
≥1 USD $16.2976
≥10 USD $14.769216
≥100 USD $13.326192
Inventory: 149
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Diameter - Ring ID 0.515 (13.08mm)
Diameter - Barrel OD 0.722 (18.34mm)
Diameter - Barrel ID 0.576 (14.63mm)
Tongue Thickness 3.048mm
Tab Thickness 0.120 3.05mm
Width - Outer Edges 1.080 27.43mm
Diameter - Inside 14.63 mm
Length - Overall 2.260 57.40mm
Width 27.43mm
Length 57.404mm
Technical
Stud Size M12
Number of Holes 1
Government Qualified No
Stud Diameter 13.08 mm
Heavy Duty No
Insulated Wire Support No
Terminal Style Single Stud Hole
Stud/Tab Size 1/2 Stud
Terminal Type Rectangular Tongue
Insulation Non-Insulated
Sealable No
Plating Tin
ELV Compliant
Wire Gauge 3/0 AWG
Contact Finish Tin
Gender Male
Color Blue
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Ampower
Published 2008
Packaging Bulk
Physical
Material Copper
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 15 Weeks
