2-327968-1 image
Favorite
2-327968-1 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description CONN TERM RECT TONG 16-22 AWG #4
PDF
/
Buying Options
Total Price: USD $0.89
Unit Price: USD $0.8888
≥1 USD $0.8888
≥10 USD $0.84392
≥100 USD $0.807136
≥500 USD $0.796048
≥1000 USD $0.695552
≥3000 USD $0.669539
Inventory: 1055
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Not Applicable
RoHS Status RoHS Compliant

Dimensions

Diameter - Ring ID 0.119 (3.02mm)
Tongue Thickness 840μm
Tab Thickness 0.031 0.79mm
Width - Outer Edges 0.237 6.02mm
Length - Overall 0.796 20.22mm
Length 20.22mm

Technical

Stud Size M2.5
Number of Holes 1
Stud Diameter 3.0226 mm
Heavy Duty No
Insulated Wire Support Yes
Terminal Style Single Stud Hole
Stud/Tab Size 4 Stud
Wire/Cable Diameter 3.56 mm
Terminal Type Rectangular Tongue
Insulation Insulated
Insulation Diameter 3.556 mm
Terminal and Terminal Block Type RING TERMINAL
Wire Gauge (Min) 22 AWG
Wire Gauge (Max) 16 AWG
ELV Compliant
Wire Gauge 16-22 AWG
Voltage - Rated AC 300V
Depth 6.01mm
HTS Code 8536.90.40.00
Color Red
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Serrated Termination
Series PIDG
Published 1997
Packaging Bulk

Physical

Insulation Material Nylon
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 9 Weeks
