1527330-3 image
Favorite
1527330-3 image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description CONN TERM RECT RING 4/0 AWG #1/2
PDF
/
Inventory: 4362
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Not Applicable
RoHS Status Non-RoHS Compliant

Dimensions

Diameter - Ring ID 0.525 (13.34mm)
Diameter - Barrel OD 0.704 (17.88mm)
Diameter - Barrel ID 0.548 (13.92mm)
Tab Thickness 0.156 3.96mm
Width - Outer Edges 1.020 25.91mm
Length - Overall 3.050 77.47mm

Technical

Terminal Style Single Stud Hole
Stud/Tab Size 1/2 Stud
Terminal Type Ring, Tubular
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
ELV Compliant
Wire Gauge 4/0 AWG
Contact Finish Tin
Reach Compliance Code unknown
HTS Code 8536.90.40.00
Color Purple
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Heavy Duty
Published 2004
Packaging Bulk

Physical

Mounting Type Free Hanging (In-Line)
Contact Material Copper
