1527313-3
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
CONN TERM RECT RING 4 AWG #1/4
PDF
/
Inventory: 8891
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status Non-RoHS Compliant
Dimensions
Diameter - Ring ID 0.275 (6.99mm)
Diameter - Barrel OD 0.360 (9.14mm)
Diameter - Barrel ID 0.252 (6.40mm)
Tab Thickness 0.108 2.74mm
Width - Outer Edges 0.500 12.70mm
Length - Overall 1.750 44.45mm
Technical
Terminal Gender FEMALE
Terminal Style Single Stud Hole
Stud/Tab Size 1/4 Stud
Terminal Type Ring, Tubular
Insulation Non-Insulated
Terminal and Terminal Block Type WIRE TERMINAL
ELV Compliant
Wire Gauge 4 AWG
Contact Finish Tin
Reach Compliance Code unknown
HTS Code 8536.90.40.00
Color Gray
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Heavy Duty
Published 2004
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Contact Material Copper
