1527272-3 image
Favorite
1527272-3 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description CONN TERM RECT RING 8 AWG #10
PDF
/
Inventory: 2042
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)

Technical

Packaging Bulk
Published 2004
Feature Heavy Duty
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp, Barrel
ECCN Code EAR99
Color Red
Gender Female
HTS Code 8536.90.40.00
Reach Compliance Code unknown
Contact Finish Tin
Wire Gauge 8 AWG
ELV Compliant
Wire/Cable Gauge 8 AWG
Terminal and Terminal Block Type RING TERMINAL
Insulation Non-Insulated
Terminal Type Ring, Tubular
Stud/Tab Size 10 Stud
Terminal Style Two Stud Holes

Dimensions

Length 44.196mm
Length - Overall 1.740 44.20mm
Width - Outer Edges 0.350 8.89mm
Tab Thickness 0.078 1.98mm
Diameter - Barrel ID 0.170 (4.32mm)
Diameter - Barrel OD 0.248 (6.30mm)
Diameter - Ring ID 0.212 (5.38mm)

Compliance

RoHS Status RoHS Compliant
Lead Free Not Applicable
