RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
CONN TERM RECT 14-16 AWG #8
PDF
/
Inventory: 6971
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Diameter - Ring ID 0.171 (4.34mm)
Tongue Thickness 790μm
Material Thickness 787.4μm
Tab Thickness 0.031 0.79mm
Width - Outer Edges 0.250 6.35mm
Length - Overall 0.795 20.19mm
Plating Thickness 2.54μm
Length 20.193mm
Technical
Stud Size M4
Stud Diameter 4.34 mm
Heavy Duty No
Insulated Wire Support Yes
Terminal Style Single Stud Hole
Stud/Tab Size 8 Stud
Wire Cross Section 2.62 mm2
Wire/Cable Diameter 4.9 mm
Terminal Type Standard
Insulation Insulated
Insulation Diameter 4.9 mm
Terminal and Terminal Block Type RING TERMINAL
Wire Gauge (Min) 14 AWG
Wire Gauge (Max) 16 AWG
ELV Compliant
Wire Gauge 14-16 AWG
Contact Finish Tin
Depth 6.35mm
HTS Code 8536.90.40.00
Color Blue
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Serrated Termination
Series Plasti-Grip
Published 2005
Packaging Bulk
Physical
Insulation Material PVC
Mounting Type Free Hanging (In-Line)
Contact Material Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 14 Weeks
