61652-1
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Terminal Rectangular Connector
PDF
/
Inventory: 10045
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
Dimensions
Tab Thickness 330.2μm
Length 9.525mm
Technical
Stud Diameter 1.6 mm
Heavy Duty No
Wire Cross Section 0.6 mm2
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Wire/Cable Gauge -24 AWG
Wire Gauge (Min) 24 AWG
Wire Gauge (Max) 26 AWG
ELV Compliant
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Rectangular
Pbfree Code yes
Packaging Tape & Reel (TR)
Physical
Mount Free Hanging
Contact Plating Unplated
Contact Material Brass
