PNL-250-2-Q

Panduit Corp
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description CONN TERM RECT LUG 6 AWG
PDF
/
Inventory: 4660
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 4 Weeks

Physical

Contact Material Copper Alloy
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Body Material Copper

Technical

Packaging Bulk
Published 2005
Series Pan-Lug?
Feature With Screw
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Screw
ECCN Code EAR99
HTS Code 8536.90.40.00
Depth 24mm
Wire Gauge 250MCM (kcmil) - 6 AWG
Wire/Cable Gauge -6 AWG
Terminal and Terminal Block Type WIRE TERMINAL
Insulation Non-Insulated
Terminal Type Lug, Grounding
Terminal Style Two Stud Holes
Terminal Gender FEMALE

Dimensions

Length 73.152mm
Length - Overall 2.880 73.15mm
Width - Outer Edges 0.940 23.88mm
Tab Thickness 0.220 5.59mm
Diameter - Ring ID 0.440 (11.18mm)

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
