PNL-1/0-2-L

Panduit Corp
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description CONN TERM RECT LUG 1/0-8 AWG
PDF
/
Inventory: 8638
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Diameter - Ring ID 0.340 (8.64mm)
Tab Thickness 0.190 4.83mm
Width - Outer Edges 0.750 19.05mm
Length - Overall 2.750 69.85mm
Length 69.85mm

Technical

Terminal Gender FEMALE
Terminal Style Two Stud Holes
Terminal Type Lug, Grounding
Insulation Non-Insulated
Terminal and Terminal Block Type WIRE TERMINAL
Wire Gauge (Min) 0 AWG
Wire Gauge (Max) 8 AWG
Wire Gauge 1/0-8 AWG
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Screw
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature With Screw
Series Pan-Lug?
Published 2005
Packaging Bulk

Physical

Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper Alloy

Supply Chain

Factory Lead Time 4 Weeks
