LCMDX35-12-Q
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
COPPER COMPRESSION METRIC LUG,
PDF
/
Inventory: 2888
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Technical
Packaging Bulk
Series LCMDX
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
HTS Code 8536.90.40.00
Contact Finish Tin
Wire Gauge 35mm2
Terminal and Terminal Block Type RING TERMINAL
Insulation Non-Insulated
Terminal Type Ring, Tubular
Stud/Tab Size M12 Stud
Terminal Style Two Stud Holes
Dimensions
Length 94.488mm
Length - Overall 3.720 94.49mm
Width - Outer Edges 0.906 23.01mm
Tab Thickness 0.071 1.80mm
Diameter - Barrel ID 0.386 (9.80mm)
Diameter - Barrel OD 0.484 (12.29mm)
Diameter - Ring ID 0.551 (14.00mm)
Compliance
RoHS Status RoHS Compliant
