LCMDX25-10-Q
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
CONN TERM RECT RING 25MM #M10
PDF
/
Inventory: 1876
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Technical
Packaging Bulk
Series LCMDX
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
HTS Code 8536.90.40.00
Contact Finish Tin
Wire Gauge 25mm2
Terminal and Terminal Block Type RING TERMINAL
Insulation Non-Insulated
Terminal Type Ring, Tubular
Stud/Tab Size M10 Stud
Terminal Style Two Stud Holes
Dimensions
Length 86.5124mm
Length - Overall 3.406 86.51mm
Width - Outer Edges 0.610 15.49mm
Tab Thickness 0.081 2.05mm
Diameter - Barrel ID 0.323 (8.20mm)
Diameter - Barrel OD 0.409 (10.39mm)
Diameter - Ring ID 0.433 (11.00mm)
Compliance
RoHS Status RoHS Compliant
