LCMDX150-12-X
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
CONN TERM RECT RING 150MM #M12
PDF
/
Inventory: 3553
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Diameter - Ring ID 0.551 (14.00mm)
Diameter - Barrel OD 0.906 (23.01mm)
Diameter - Barrel ID 0.732 (18.59mm)
Tab Thickness 0.179 4.55mm
Width - Outer Edges 1.319 33.50mm
Length - Overall 4.606 117.00mm
Length 116.9924mm
Technical
Terminal Style Two Stud Holes
Stud/Tab Size M12 Stud
Terminal Type Ring, Tubular
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Wire Gauge 150mm2
Contact Finish Tin
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Series LCMDX
Published 2012
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
