LCMDX120-14-X
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
CONN TERM RECT RING 120MM #M14
PDF
/
Inventory: 4696
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Diameter - Ring ID 0.630 (16.00mm)
Diameter - Barrel OD 0.827 (21.01mm)
Diameter - Barrel ID 0.650 (16.51mm)
Tab Thickness 0.169 4.29mm
Width - Outer Edges 1.201 30.51mm
Length - Overall 4.665 118.49mm
Length 118.491mm
Technical
Terminal Style Two Stud Holes
Stud/Tab Size M14 Stud
Terminal Type Ring, Tubular
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Wire Gauge 120mm2
Contact Finish Tin
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Series LCMDX
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
