LCMD500-12-1

Panduit Corp
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description Pan-Lug? ROHS3Compliant 2011 Non-Insulated Terminal Rectangular Connector 57.5mm
PDF
/
Inventory: 9249
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Dimensions

Length - Overall 6.476 164.49mm
Width - Outer Edges 2.264 57.51mm
Tab Thickness 0.350 8.89mm
Diameter - Barrel ID 1.220 (30.99mm)
Diameter - Barrel OD 1.575 (40.01mm)
Diameter - Ring ID 0.551 (14.00mm)
Length 164.4904mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant

Technical

Terminal Style Two Stud Holes
Stud/Tab Size M12 Stud
Wire Cross Section 500 mm2
Terminal Type Ring, Tubular
Insulation Non-Insulated
Terminal and Terminal Block Type RING TERMINAL
Wire Gauge 500mm2
Depth 57.5mm
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2011
Packaging Bulk

Physical

Weight 748.42741g
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper

Supply Chain

Factory Lead Time 4 Weeks
