LCMD240-12-5
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal (7.3/0)AWG 131mm 37.5mm Tin
PDF
/
Buying Options
Total Price: USD $55.62
Unit Price: USD $55.6248
≥1 USD $55.6248
≥10 USD $54.03464
≥100 USD $49.266888
Inventory: 51
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Weight 1.111301kg
Technical
Packaging Bulk
Published 2011
Series Pan-Lug?
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
HTS Code 8536.90.40.00
Depth 37.5mm
Wire Gauge 240mm2
Terminal and Terminal Block Type RING TERMINAL
Insulation Non-Insulated
Terminal Type Ring, Tubular
Wire Cross Section 240 mm2
Stud/Tab Size M12 Stud
Terminal Style Two Stud Holes
Dimensions
Length 130.9878mm
Length - Overall 5.157 131.00mm
Width - Outer Edges 1.476 37.49mm
Tab Thickness 0.209 5.31mm
Diameter - Barrel ID 0.819 (20.80mm)
Diameter - Barrel OD 1.024 (26.01mm)
Diameter - Ring ID 0.551 (14.00mm)
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
