LCMD16-00-Q
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
Lug Terminal 6AWG 81.2mm 15mm Tin
PDF
/
Inventory: 5945
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Diameter - Barrel OD 0.283 (7.19mm)
Diameter - Barrel ID 0.217 (5.51mm)
Tab Thickness 0.043 1.09mm
Width - Outer Edges 0.591 15.00mm
Length - Overall 3.197 81.20mm
Length 81.2038mm
Technical
Terminal Style No Stud Hole
Wire Cross Section 16 mm2
Terminal Type Ring, Tubular
Insulation Non-Insulated
Terminal and Terminal Block Type WIRE TERMINAL
Wire/Cable Gauge 6 AWG
Wire Gauge 16mm2
Depth 15mm
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Pan-Lug?
Published 2011
Packaging Bulk
Physical
Weight 340.194306g
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
