LCMC50-12-E

Panduit Corp
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description CONN TERM RECT RING 50MM #M12
PDF
/
Inventory: 3762
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 4 Weeks

Physical

Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)

Technical

Packaging Bulk
Published 2013
Series LCMC
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
HTS Code 8536.90.40.00
Contact Finish Tin
Wire Gauge 50mm2
Insulation Non-Insulated
Terminal Type Ring, Tubular
Stud/Tab Size M12 Stud
Terminal Style Two Stud Holes

Dimensions

Length 110.7948mm
Length - Overall 4.362 110.79mm
Width - Outer Edges 0.906 23.01mm
Tab Thickness 0.071 1.80mm
Diameter - Barrel ID 0.386 (9.80mm)
Diameter - Barrel OD 0.484 (12.29mm)
Diameter - Ring ID 0.551 (14.00mm)

Compliance

RoHS Status ROHS3 Compliant
