LCMC185-14-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
CONN TERM RECT RING 185MM #M14
PDF
/
Inventory: 8037
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Diameter - Ring ID 0.630 (16.00mm)
Diameter - Barrel OD 0.906 (23.01mm)
Diameter - Barrel ID 0.732 (18.59mm)
Tab Thickness 0.173 4.39mm
Width - Outer Edges 1.319 33.50mm
Length - Overall 5.890 149.61mm
Length 149.606mm
Technical
Terminal Style Two Stud Holes
Stud/Tab Size M14 Stud
Terminal Type Ring, Tubular
Insulation Non-Insulated
Wire Gauge 185mm2
Contact Finish Tin
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series LCMC
Published 2013
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
