LCMB70-10-X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
CONN TERM RECT RING 70MM #M10
PDF
/
Inventory: 5310
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Technical
Packaging Bulk
Published 2013
Series LCMB
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
HTS Code 8536.90.40.00
Contact Finish Tin
Wire Gauge 70mm2
Insulation Non-Insulated
Terminal Type Ring, Tubular
Stud/Tab Size M10 Stud
Terminal Style Single Stud Hole
Dimensions
Length 68.199mm
Length - Overall 2.685 68.20mm
Width - Outer Edges 0.819 20.80mm
Tab Thickness 0.112 2.85mm
Diameter - Barrel ID 0.453 (11.51mm)
Diameter - Barrel OD 0.559 (14.20mm)
Diameter - Ring ID 0.433 (11.00mm)
Compliance
RoHS Status ROHS3 Compliant
