LCMB630-20-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
CONN TERM RECT RING 630MM #M20
PDF
/
Inventory: 6362
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Diameter - Ring ID 0.866 (22.00mm)
Diameter - Barrel OD 1.732 (43.99mm)
Diameter - Barrel ID 1.358 (34.49mm)
Tab Thickness 0.370 9.40mm
Width - Outer Edges 2.480 62.99mm
Length - Overall 6.264 159.11mm
Length 159.1056mm
Technical
Terminal Style Single Stud Hole
Stud/Tab Size M20 Stud
Terminal Type Ring, Tubular
Insulation Non-Insulated
Wire Gauge 630mm2
Contact Finish Tin
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series LCMB
Published 2013
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper
Supply Chain
Factory Lead Time 4 Weeks
