LCMB500-12-3

Panduit Corp
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description CONN TERM RECT RING 500MM #M12
PDF
/
Inventory: 7797
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Diameter - Ring ID 0.551 (14.00mm)
Diameter - Barrel OD 1.575 (40.01mm)
Diameter - Barrel ID 1.220 (30.99mm)
Tab Thickness 0.350 8.89mm
Width - Outer Edges 2.264 57.51mm
Length - Overall 5.894 149.71mm
Length 149.7076mm

Technical

Terminal Style Single Stud Hole
Stud/Tab Size M12 Stud
Terminal Type Ring, Tubular
Insulation Non-Insulated
Wire Gauge 500mm2
Contact Finish Tin
HTS Code 8536.90.40.00
ECCN Code EAR99
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series LCMB
Published 2013
Packaging Bulk

Physical

Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper

Supply Chain

Factory Lead Time 4 Weeks
