LCMB400-12-6
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
CONN TERM RECT RING 400MM #M12
PDF
/
Inventory: 6987
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Technical
Packaging Bulk
Published 2013
Series LCMB
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
HTS Code 8536.90.40.00
Contact Finish Tin
Wire Gauge 400mm2
Insulation Non-Insulated
Terminal Type Ring, Tubular
Stud/Tab Size M12 Stud
Terminal Style Single Stud Hole
Dimensions
Length 127.4064mm
Length - Overall 5.016 127.40mm
Width - Outer Edges 1.949 49.50mm
Tab Thickness 0.295 7.49mm
Diameter - Barrel ID 1.063 (27.00mm)
Diameter - Barrel OD 1.358 (34.49mm)
Diameter - Ring ID 0.551 (14.00mm)
Compliance
RoHS Status ROHS3 Compliant
