LCMB10-5-L
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
CONN TERM RECT RING 10MM #M5
PDF
/
Buying Options
Total Price: USD $3.85
Unit Price: USD $3.8456
≥1 USD $3.8456
≥10 USD $3.73912
≥100 USD $3.6696
Inventory: 40
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Technical
Packaging Bulk
Published 2013
Series LCMB
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
ECCN Code EAR99
HTS Code 8536.90.40.00
Contact Finish Tin
Wire Gauge 10mm2
Insulation Non-Insulated
Terminal Type Ring, Tubular
Stud/Tab Size M5 Stud
Terminal Style Single Stud Hole
Dimensions
Length 43.7896mm
Length - Overall 1.724 43.79mm
Width - Outer Edges 0.433 11.00mm
Tab Thickness 0.047 1.19mm
Diameter - Barrel ID 0.177 (4.50mm)
Diameter - Barrel OD 0.244 (6.20mm)
Diameter - Ring ID 0.217 (5.51mm)
Compliance
RoHS Status ROHS3 Compliant
