LCMAX6-5-C
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
CONN TERM RECT RING 4-6MM #M5
PDF
/
Inventory: 4150
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Diameter - Ring ID 0.217 (5.51mm)
Diameter - Barrel OD 0.217 (5.51mm)
Diameter - Barrel ID 0.150 (3.81mm)
Tab Thickness 0.046 1.17mm
Width - Outer Edges 0.394 10.00mm
Length - Overall 1.083 27.51mm
Length 27.5082mm
Technical
Terminal Style Single Stud Hole
Stud/Tab Size M5 Stud
Terminal Type Ring, Tubular
Insulation Non-Insulated
Wire Gauge (Min) 4 AWG
Wire Gauge (Max) 6 AWG
Wire Gauge 4-6mm2
Contact Finish Tin
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Series LCMAX
Published 2012
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
Supply Chain
Factory Lead Time 1 Weeks
