LCMAX50-8-L
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
CONN TERM RECT RING 50MM #M8
PDF
/
Inventory: 9926
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Diameter - Ring ID 0.354 (8.99mm)
Diameter - Barrel OD 0.559 (14.20mm)
Diameter - Barrel ID 0.453 (11.51mm)
Tab Thickness 0.112 2.85mm
Width - Outer Edges 0.819 20.80mm
Length - Overall 2.106 53.50mm
Length 53.4924mm
Technical
Terminal Style Single Stud Hole
Stud/Tab Size M8 Stud
Terminal Type Ring, Tubular
Insulation Non-Insulated
Wire Gauge 50mm2
Contact Finish Tin
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Series LCMAX
Published 2012
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
