LCMAX185-10-X
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description
CONN TERM RECT RING 185MM #M10
PDF
/
Inventory: 7729
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Diameter - Ring ID 0.433 (11.00mm)
Diameter - Barrel OD 1.024 (26.01mm)
Diameter - Barrel ID 0.819 (20.80mm)
Tab Thickness 0.209 5.31mm
Width - Outer Edges 1.476 37.49mm
Length - Overall 3.406 86.51mm
Length 86.5124mm
Technical
Terminal Style Single Stud Hole
Stud/Tab Size M10 Stud
Terminal Type Ring, Tubular
Insulation Non-Insulated
Wire Gauge 185mm2
Contact Finish Tin
Termination Crimp, Barrel
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Series LCMAX
Published 2012
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Copper
