LCMAX10-10-C

Panduit Corp
RoHS
/
Package /
Category Connectors, Interconnects / Terminals - Rectangular Connectors
Description CONN TERM RECT RING 10MM #M10
PDF
/
Inventory: 1642
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 1 Weeks

Physical

Contact Material Copper
Mount Free Hanging
Mounting Type Free Hanging (In-Line)

Technical

Packaging Bulk
Published 2012
Series LCMAX
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Termination Crimp, Barrel
Contact Finish Tin
Wire Gauge 10mm2
Terminal and Terminal Block Type RING TERMINAL
Insulation Non-Insulated
Terminal Type Ring, Tubular
Stud/Tab Size M10 Stud
Terminal Style Single Stud Hole

Dimensions

Length 36.703mm
Length - Overall 1.445 36.70mm
Width - Outer Edges 0.591 15.00mm
Tab Thickness 0.043 1.09mm
Diameter - Barrel ID 0.217 (5.51mm)
Diameter - Barrel OD 0.283 (7.19mm)
Diameter - Ring ID 0.433 (11.00mm)

Compliance

RoHS Status RoHS Compliant
